You need to ground A-20 (A = 40 Pin connector at ECU) if that doesn't work then connect A-20 to pin 69 at the ECU connector. Grounding it should work just fine though.
Having a similair problem with my swap in which I have relocated the battery to the back. It will only start after I have it jumped I have noticed but I havent driven the car yet to really charge the battery. Im still staying tuned here though for a resolution. I havent tested the battery or alt yet
Is their a pinout diagram of the ecu somewhere? And so your saying if my A-20 pin is hooked up and still doesn't work, then connect it to pin 69 on ECU? what will this do? Just curious thanks
so i checked the grounds and they are good. Also checked injector clips and coilpacks and they tested fine. I did however, unplug the ECU and opened it and came across two circuits that were burned. Me and my friends traced them to the Malfunction Indicator Lamp and the TRAC ECU... any ideas? It still seems like its drawing power from somewhere, and i am not getting spark...
Well that sux. I know you said you traced down the burned circuits, but keep In mind that in integrated circuit board technology there is circuit paths that rely on feedback voltage from others. If you have anything burned on the board, then it will render any other hardware dependent on that circuit path inoperable...like the ability to send spark.
turns out the injectors are on the same curcuit as the TRAC ECU is, doesnt say anything about spark. *crosses fingers* but its all making sense... i slammed on my brakes on top of a hill which in turn, kicked my ABS/TRAC ECU on. But the other question is, why would it crap out like that? why would it burn the circuit? Bad wiring somewhere?
Someone correct me if I am wrong, but if there is no power to the injectors, does'nt that kill the spark signal too ? I would say hop on ebay and get a used ecu, I just have a feeling its the ecu itself. I study electronics at school btw.
I need help! Trying to figure out what kind of resistor is the one that is burnt. I know most resistors have color bands that help you figure this out,but the problem is the resistor is solid light blue in color. Any ideas what it is?
Solid blue is going to be another capacitor. Resistors are cream colored, with the various colored bands. The cream color is the base color as to better show the different colored bands. Post a pic of it up and I will tell you what it is. If it is what I think, you can get another capacitor and solder it in
