Factory 7MGTE ignition timing figures?

[BLACKCAT]

Does anyone know the factory 7MGTE ignition timing figures at the various rpm/boost levels?
thanks



[CajunKenny]

Attached is an image of the timing map. Haven't figured out how to attach files to this post. I would not use this map without a very capable knock-sense algorithm monitoring things. The stock ECU knock sensor is fast and pulls timing a lot during normal operation.

^This is the latest data. I can tell you from experience that the ECU adds approximately 11* at around 5200 rpm's regardless of boost level.
