Motor mounts?

[7Mboost]

I have the 7mgte I pulled out of my 89 with square motor mounts, and I'm trying to put this motor in my 91. Since the round mm in the 91 were no good, I grabbed the round motor mounts and brackets off my wrecked 89 NA.

Now the driver's side motor mount attaches to the fuel filter bracket I think, but the that bracket hits the mm bracket. What am I missing here?



[SevenMKIII]

If you used square mm in an 89+ wouldn't you have to have to have a pre-89 crossmember?

Fuel filter is in the back of the car, are you talking about the j-tube?

edit: Do you have them on the right side? 89+ mm one side is shorter than the other. The j-tube bolts to the block...I'm still lost at what you're describing. Can you get a picture of it? (Sorry if there is one, Websense at work blocks all pictures)



[7Mboost]

Yeah that's what I'm gonna get not I gotta run to the shop.



[7Mboost]

Ok so The bracket circled will not fit up the through the tranny bellhouse mounting bracket and go through to the threads because it hits on the mm bracket.



[7Mboost]

Any help?



[SevenMKIII]

I can't see pictures at work, otherwise I might be able to help a little more.



[3p141592654]

I don't have a clear shot at it, but from the lousy picture I have there is no bracket attached to that bolt.



[3p141592654]

Okay, I understand now. That bracket is for the engine shock absorber used only with the square brackets. That part is not used with the round liquid mounts.

http://www.cygnusx1.net/Supra/Library/EPC/291420/catalog.aspx?F=1107&P=1



[White Zombie]

Ok so the square ones had an engine damper ?
Someone said that they could buy the round mm for around 50$ Where the hell did this come from? I have been looking and cant seem to locate new motor mounts anywhere ( for a reasonable price like 50$)

Any help would be a step forward!



[SevenMKIII]

7MBoost: I'm home now, I have no clue what that bracket attached at the motor mount bolts is. My transmission wings bolted to the block behind the motor mounts (I'm pre-89). Sorry :dunno:

White Zombie: I have a pair of 89+ motor mounts, just the metal part not the circle rubber if you want them.



[White Zombie]

Sorry my round ones are completly separated ! I have some square ones but dont really want to use them. Or maybe I cant since My car is a 90 ?



[mhopemk3]

Are you sure that motor mount is on the correct side? I am trying to recall how it was on that engine I bought from you.. I just used my 89 mounts on the 91 block..



[TurboWarrior]

If your mounts are square can you still use the round ones?



[7Mboost]

Ok so why does the engine brace/dampner thing have 2 mouting holes?



[7Mboost]

Anyone? This is the only thing holding up my build.



[7Mboost]

x2 ^



[3p141592654]

I already told you.... you don't use the damper with the round mounts. Toss it away.



[AaronsSupraMKIII]

I couldn't find any round mounts, exept 150 bucks each from toyota, so I bought some solid mounts for 120. They sure wont break. Have to deal with some vibration though.



[kawkoretsx]

I don't think the round and square mounts are interchangable. When I did my second swap themotor came with newer round motor mounts. They were a different length though, so I didn't use them. I have an 87 that uses a dampner with the square motor mounts.



[3p141592654]

They are not interchangeable without swapping crossmembers, but 7MB apparently has at least three supras, so it seems he has enough parts to make it all work.
